LARGEST MOBILE HORIZONTAL GRINDER IN USA

IMG_2324_optimized_200

CT Mulch

WSM 5472 Titan Horizontal Grinder - Trailer Mounted

Stationary "Yard Only" Grinding Operations

Application: Pre-shredded bark, aged wood, and limited white wood

Specs:

  • Rotor Dimensions: 54" diameter × 72" width, fully machined.
  • Hammers: 3.5" wide alloy steel rigid hammers with reversible/replaceable tips (28 hammers, 150 lbs each)
  • Drive System:
    • Dual 700 HP motors for belt-driven operation.
    • 800-900 RPM hog operation.
  • Conveyor System:
    • Infeed Chain Conveyor: 20' long with 56" wide pan.
    • Discharge Belt Conveyor: 25' long with a magnetic head pulley and 60" wide belt.

Key Features

  • Heavy-Duty Rotor Assembly: Equipped with SKF 22244 double-row spherical roller bearings in cast steel pillow block housings.
  • Titan Design: Features heavy-duty chain infeed and large-diameter feed roll for superior material handling.
  • Processing Capacity: Up to 500 yards per hour (capacity varies by material size and feeding method).
  • Remote Control: Enables radio-controlled infeed adjustments.
  • Wide Feed Opening: Maximum feed opening of 40", capable of processing up to 36"
    diameter logs.
  • Abrasion-Resistant Construction: Replaceable interior wear liners, drilled and tapped for easy maintenance
Image (1)

BUILT TOUGH.

BUILT TO LAST.
